CR200X

Name: CR200X
Brand: Campbell Scientific
SKU: 21937
Availability: Discontinued

Datalogger

CR200X

Retired

Datalogger

No longer available to order

This product is retained for service, documentation, and compatibility information.

Replaced by

CR300
Measurement and Control Datalogger
CR310
Measurement and Control Datalogger

Model:: CR200X
Item Number:: 21937
Warranty:: 3 years

Overview

The CR200X, our smallest lowest-cost data logger, provides stand-alone operation in harsh, remote environments. It reads input from one or two sensors, then transmits the data using communication peripherals. CRBasic, its full programming language, supports simple or complex programming. Multiple CR200Xs can be configured as a network, or units can be deployed individually.

Key Advantages

Our Smallest,
Lowest-Cost Data Logger

Technical Description

The CR200X has several input channels for measuring a variety of sensors. Gas discharge tubes provide rugged electrostatic discharge protection for the inputs.

The CR200X does not make differential measurements and is not compatible with SDM devices, multiplexers, or thermocouples (refer to the Compatibility information for compatible sensors, peripherals, and software). Recalibration services are not offered for the CR200X datalogger.

Benefits

Ideal applications include wind energy, rural water, water level/flow, aquaculture, water quality
Campbell Scientific’s smallest, lowest cost data logger
Gas Discharge Tube (GDT) protected inputs
Optimal for measuring one or two simple sensors
Makes SDI-12, single-ended analog, pulse, switch closure, and bridge measurements
Battery-backed clock that ensures accurate time is maintained while data logger is disconnected from battery power
Program with LoggerNet, PC400, or Short Cut to fit your setup
PakBus, Modbus, and SDI-12 protocols supported

Specifications

-NOTE-: Note: Additional specifications are listed in the CR200X-Series Specifications Sheet.
Maximum Scan Rate: 1 Hz
Analog Channels: The single-ended analog inputs can also be used as control ports.
5 single-ended (no differential)
individually configured
Pulse Count Channels: 2
Switched Excitation Channels: 2 voltage
Digital Ports: Certain digital ports can be used to count switch closures.
2 I/O
Communication Ports: 1 RS-232
Switched Battery Port: 1
Input Voltage Range: 0 to 2500 mV
Analog Voltage Accuracy: ±(0.25% of reading + (1.2 mV)x(offset))
at -40° to +50°C
Analog Voltage Resolution: 0.6 mV
A/D Bits: 12
Operating Temperature: -40° to +50°C
Power Requirements: 7 to 16 Vdc
Typical Current Drain: ~0.2 mA
(quiescent)
~3 mA
(active)
Clock Accuracy: 8.2 min./month
(@ -40° to +50°C)
1 min./month
(@ +25°C)
Protocols Supported: PakBus (leaf node only), SDI-12
CE Compliance Standards to which Conformity Is Declared: IEC61326:2002
Warranty: 3 years
Dimensions: 14.0 x 7.6 x 4.8 cm
(5.5 x 3.0 x 1.9 in.)
Weight: 242 g
(8.5 oz)

Memory

Final Storage: 512 kB of flash memory for approximately 125,000 data points
Operating System: 106 kB of flash memory
Intermediate Storage: 8 kB of SRAM for communication buffers, calculations, variables, etc.

Accessories

(5)

Common Accessories

(4)

Other Accessories

(1)

7977
100 Ohm Shunt Resistor Assembly
This shunt resistor converts a probe's 4-20 mA signal to a millivolt signal that can be measured by this data logger.
Orderable

Replacement Parts

(4)

Similar Products

(2)

Compatibility

Communications

The CR200X can communicate with a PC via direct connect, NL201 Network Link Interface, NL240 Wi-Fi Network Link, MD485 multidrop modem, and digital cellular modems. Data can be viewed on an iOS device, an Android device, CD295 DataView II Display, or a user-supplied PDA. To use an iOS or Android device, go to the Apple Store or Google Play and download our LoggerLink Mobile Apps free of charge. User-supplied PDAs require either PConnect or PConnectCE software.

Measurement & Control Peripherals

The CR200X is not compatible with SDM devices and multiplexers.

Sensors

The CR200X can measure a variety of sensors including SDI-12 sensors and 4 to 20 mA sensors. It cannot make differential measurements and is not compatible with the freezing-rain/ice, fuel moisture/temperature, geographic position, present weather, soil heat flux, soil matric water potential, and strain sensors listed on our price lists.

Enclosures

Applications with minimal power requirements can use the ENC200 enclosure to house the data logger and the pn 16869 sealed rechargeable battery. The ENC200 cannot house a barometer or a battery that is larger than the pn 16869. However, an ENC10/12 or ENC12/14 enclosure is adequate for most CR200X-based systems.

Power Supplies

The CR200X uses an external power supply and has a built-in regulator. When connected to the on-board charging circuit, the sealed rechargeable battery should be 7 A h or smaller. Using larger batteries with the data logger's built-in charger may result in excessive PC board heating. This is especially a concern when the battery is deeply discharged or failing with a shorted cell. Campbell Scientific also recommends that solar panels be 10 W or less and wall chargers be 1 A or smaller.
