05106-L

Name: 05106-L
Brand: Campbell Scientific
SKU: 16464
Availability: Discontinued

Wind Monitor, Marine Version

05106-L

Retired

Wind Monitor, Marine Version

No longer available to order

This product is retained for service, documentation, and compatibility information.

Replaced by

05108
Wind Monitor-HD

Model:: 05106-L
Item Number:: 16464
Warranty:: 1 year

Overview

Designed for offshore and marine applications, the 05106 is a lightweight, robust instrument that measures wind speed and direction. Manufactured by R. M. Young, this wind monitor is cabled for use with Campbell Scientific data loggers.

Key Advantages

Reliable, Accurate Wind Measurements
Suitable for marine applications

Technical Description

The 05106 Wind Monitor-MA is made out of rigid UV-stabilized thermoplastic with stainless steel and anodized aluminum fittings. The thermoplastic material resists corrosion from sea air environments and atmospheric pollutants. It uses stainless-steel precision-grade ball bearings for the propeller shaft and vertical shaft bearings.

To make it more durable in offshore and marine applications, the 05106 has waterproof bearing lubricant and a sealed, heavy-duty cable pigtail instead of the standard junction box.

The 05106 measures wind speed with a helicoid-shaped, four-blade propeller. Rotation of the propeller produces an ac sine wave that has a frequency directly proportional to wind speed. The ac signal is induced in a transducer coil by a six-pole magnet mounted on the propeller shaft. The coil resides on the non-rotating central portion of the main mounting assembly, eliminating the need for slip rings and brushes.

Wind direction is sensed by the orientation of the fuselage-shaped sensor body, which is connected to an internal potentiometer. The data logger applies a known precision excitation voltage to the potentiometer element. The output is an analog voltage signal directly proportional to the azimuth angle.

Product Notes

requires CM220 or 17953

Benefits

Waterproof bearing lubricant and a sealed, heavy-duty cable pigtail instead of the standard junction box make it more durable at marine and off-shore locations
Compatible with most Campbell Scientific data loggers
Rugged enough for harsh environments
Constructed with thermoplastic material that resists corrosion from sea-air environments and atmospheric pollutants
Compatible with the LLAC4 4-channel Low-Level AC-Conversion Module, which increases the number of anemometers one data logger can measure
Uses stainless-steel, precision-grade ball bearings for the propeller shaft and vertical shaft bearings
Compatible with the CWS900-series interfaces, allowing it to be used in a wireless sensor network

Specifications

Operating Temperature Range: -50° to +50°C
(assuming non-riming conditions)
Mounting Pipe Description: 34 mm (1.34 in.) OD
Standard 1.0-in. IPS schedule 40
Propeller Diameter: 18 cm
(7.1 in.)
Overall Height: 37 cm
(14.6 in.)
Overall Length: 55 cm
(21.7 in.)
Main Housing Diameter: 5 cm
(2.0 in.)
Weight: 1.5 kg
(3.2 lb)

Wind Speed

Range: 0 to 100 m/s
(0 to 224 mph)
Accuracy: ±0.3 m/s (0.6 mph) or 1% of reading
Starting Threshold: 1.1 m/s
(2.4 mph)
Distance Constant: 2.7 m
(8.9 ft) 63% recovery
Output: ac voltage (three pulses per revolution)

90 Hz (1800 rpm) = 8.8 m/s (19.7 mph)
Resolution: (0.0980 m s^-1)/(scan rate in seconds) or (0.2192 mph)/(scan rate seconds)

Wind Direction

Mechanical Range: 0 to 360°
Electrical Range: 355°
(5° open)
Accuracy: ±3°
Starting Threshold: 1.1 m/s
(2.4 mph) at 10° displacement
Distance Constant: 1.3 m
(4.3 ft) 50% recovery
Damping Ratio: 0.3
Damped Natural Wavelength: 7.4 m
(24.3 ft)
Undamped Natural Wavelength: 7.2 m
(23.6 ft)
Output: Analog dc voltage from potentiometer
(resistance 10 kohm)
Linearity is 0.25%.
Life expectancy is 50 million revolutions.
Voltage: Power switched excitation voltage supplied by data logger
