Data Loggers / Aspen 10
Aspen 10 Edge Device for a Single Sensor
Makes a Sensor IoT Cloud Connected
weather applications water applications energy applications gas flux and turbulence applications infrastructure applications soil applications


The revolutionary Aspen™10 Internet of Things (IoT) Edge Device allows users to easily connect their environmental sensor to the cloud. It is rugged and durable and may be mounted outdoors without the need for a second enclosure. It has an integrated solar panel and internal rechargeable battery, making the Aspen 10 a truly self-sustaining device.

The Aspen 10 is also small and compact, which makes it easy to install in a variety of locations without disturbing the environment it is monitoring. An integrated IoT cellular modem allows the Aspen 10 to transmit data to the cloud, and a global positioning system (GPS) receiver provides automated installation location.

Setting up the Aspen 10 to read your sensor is quick and easy thanks to a new sensor interface technology that allows automatic identification of any sensor with an SDI-12 identification. The Aspen 10 publishes this ID to the cloud, in return receiving a customized measurement configuration and program for your specific sensor and application. You can then monitor your data from anywhere.

Read More

Benefits and Features

  • IoT device using local cellular networks as the low-power wide-area network (LPWAN)
  • Cellular CAT M1 for worldwide roaming
  • Geolocation to automatically determine the edge device's location
  • Solar charging to keep the IoT device operational indefinitely using just a few hours of daily sunlight
  • Internal rechargeable LiFePO4 battery with reserve power for more than one month's operation without charge for all supported sensors
  • Smart sensor detection and identification
  • Smart sensor power automatic optimization for the attached sensor
  • Simple zip tie system for mounting to almost anything
  • Water-resistant enclosure for installation in most environments
  • On/off switch for simple operation
  • Status LED for operation without a smartphone
  • Near Field Communication (NFC)/Bluetooth for operation with a smartphone to allow on-site analysis through the CampbellGo App
  • Optimal security using Message Queuing Telemetry Transport (MQTT) with Transport Layer Security (TLS) mutual authentication


Aspen 10 mounted to a pole (pole not included)
Aspen 10 mounted to a pole (pole not included)
Aspen 10 mounted to a pole (pole not included)
Aspen 10 Edge Device
Aspen 10 Edge Device
Aspen 10 Edge Device
Aspen 10 Edge Device
Aspen 10 Edge Device
Aspen 10 mounted to a pole in a field (pole not included)

Detailed Description

The Aspen 10 is a multipurpose, compact, entry-level edge device with a simple plug-and-play interface. Supported sensors measure hydrological, meteorological, environmental, and industrial phenomena. The Aspen 10 is part of the IoT and makes sensor data accessible anywhere via the Aspen 10's compatibility with the MQTT protocol and its integration with CampbellCloud. The Aspen 10 provides maintenance-free sensor power and automates cellular connectivity, data storage, and data forwarding to CampbellCloud, where users can both visualize their data and manage API access.

The Aspen 10 is similar to a full Campbell Scientific system and comprises a data logger, wiring terminals, enclosure, solar panel, charge regulator, battery, modem, and antenna—all in one small package.

Compatible sensors are cabled using an eight-pin M12 connector. A detect pin lets the Aspen 10 know that it has connected to a sensor with an SDI-12 capability of self-identification. After identifying the sensor, the Aspen 10 connects to CampbellCloud to retrieve the appropriate configuration and program for that sensor, which enable the edge device to power the sensor appropriately and make accurate analog or digital measurements.

A free app, CampbellGo, enables secure NFC/Bluetooth pairing between a phone and the Aspen 10. This greatly simplifies the installation process with real-time sensor readings, diagnostic tools, and data-to-cloud delivery information while you are on-site. This gives you confidence that everything is working from end to end before leaving the installation site.

All of this allows you to collect data from the selected sensor in the location you need from practically anywhere on the globe.

Aspen 10-Compatible IoT Solutions

The Aspen™10 Internet of Things (IoT) Edge Device can be paired with many of our digital sensors. Click on any of the images below to learn more about our growing list of compatible sensors:

ClimaVue 50 + Aspen 10 Solutions

ClimaVue™50 + Aspen 10
Get next-gen IoT solutions for advanced meteorological monitoring.

HygroVue 10 + Aspen 10 Solutions

HygroVue™10 + Aspen 10
Acquire accurate humidity and air temperature monitoring with next-gen IoT solutions.

RainVue 10 + Aspen 10 Solutions

RainVue™10 + Aspen 10
Access economical solutions for rainfall monitoring.

RainVue 20 + Aspen 10 Solutions

RainVue™20 + Aspen 10
Experience solutions tailored for high-intensity, smart rainfall applications.

SnowVue 10 + Aspen 10 Solutions

SnowVue™10 + Aspen 10
Discover next-gen solutions for precision snow-depth monitoring.

SoilVue 10 + Aspen 10 Solutions

SoilVue™10 + Aspen 10
Use advanced yet easy solutions for soil profile monitoring.

TempVue 20 + Aspen 10 Solutions

TempVue™20 + Aspen 10
Employ solutions for air temperature measurements that surpass World Meteorological Organization (WMO) recommendations.

Wintersense SDI-12 + Aspen 10 Solutions

Wintersense SDI-12 + Aspen 10
Benefit from precision IoT solutions for road monitoring and route-based winter maintenance decisions.


Processor 32-bit arm cortex (CPU)
  • 2 MB flash
  • 640 KB SRAM
Program Execution Period 1 s to 1 day; 1 s increments
Real-Time Clock Resolution ±1 s
Real-Time Clock Accuracy Synchronized with CampbellCloud once per day
Operating Temperature Range
  • -20 to +60°C (standard)
  • -40 to +75°C (extended)
  • Outdoor environment
Maximum Scan Rate 1 s
Communication Protocols SDI-12, HTTP(S), MQTT
Case Material
  • High-impact-resistant and UV-resistant ASA, recycle code 7
  • IP65 water-resistant rated, Gore-Tex breathability
Digital I/O Terminals are configured for SDI-12.
Certifications CB Certificate Number NO127343
Dimensions 16.2 x 8.0 x 5.8 cm (6.4 x 3.2 x 2.3 in.)
  • 395 g (0.9 lb) for -ST option
  • 352 g (0.8 lb) for -XT option


Battery Note: Charge and discharge characteristics are controlled internally according to battery type.
Battery for -20° to +60°C
(-ST) Option
3.2 Vdc, 7.2 Ah, Li-Po PHD26650
Battery for -40° to +75°C
(-XT) Option
3.65 Vdc, 5.6 Ah, Li-ion Saft MP176065 xtd
Average Current Drain
  • <0.35 uA (deep sleep)
  • <1 mA (idle)
  • 10 uA (ultra-low power) for 5 Vdc sensor power supply
  • 5 mA for 5 Vdc sensor power supply
  • 14.3 mA for 8 Vdc sensor power supply
  • 30 mA for 12 Vdc sensor power supply

Power Output

-NOTE- Regulated 5, 8, or 12 Vdc (disabled when battery capacity <0.5 Ah)
5 Vdc Current Limit
  • 30 mA (ultra-low power)
  • 210 mA
8 Vdc Current Limit 210 mA
12 Vdc Current Limit 210 mA


Protocols SDI-12
Internet Protocols HTTP(S), MQTT
Near Field Communication (NFC) Target device compatible with CampbellGo
Bluetooth Low Energy (BLE)
  • Compatible with CampbellGo
  • Maximum distance of 50 m (165 ft)
SDI-12 One SDI-12 compliant terminal meets SDI-12 Standard v 1.4.


Note: The following shows notable compatibility information. It is not a comprehensive list of all compatible or incompatible products.


Product Compatible Note
BaroVue 10 AQ sensor pigtail cable required
ClimaVue 50 AQ conversion cable required
CS451 A151 termination box required
CS456 A151 termination box required
HygroVue 10 AQ conversion cable required
RainVue 10 AQ conversion cable required
RainVue 20 AQ conversion cable required
SoilVue 10 AQ conversion cable required
TempVue 20 No additional cable required
Wintersense SDI-12 No additional cable required

Additional Compatibility Information

The Aspen 10 is only compatible with CampbellCloud. It is not compatible with LoggerNet or any of its derivatives. To access CampbellCloud, please visit our CampbellCloud hosted site.

This edge device is compatible with sensors that support SDI-12 communications, respond to the identify command, and are wired using an M12 eight-pin connector code A as specified by Campbell Scientific.

Please note that the Aspen 10 will not power sensors with heaters, and it does not allow high-frequency data collection.
