RS-485 Multidrop Interface

MD485

Orderable

RS-485 Multidrop Interface

Pricing

Request a quote Have pricing access? Sign in

Configuration

Interface**-ST -25 to +50C (Ships as 16961, 16675, & 10873)MD485-STPart Number: 42058
Interface**-XT -55 to +85C (Ships as 33954, 16675, & 10873)MD485-XTPart Number: 42059

Qty

Select a configuration to add to your quote

Model:: MD485
Item Number:: MD485
Warranty:: 1 year

Overview

The MD485 is an intelligent RS-485 interface that permits a PC to address and communicate with one or more data loggers over a distance of up to 1200 m. This interface also supports data-logger-to-data-logger communication, callback from a remote data logger, PC-to-printer communications, and digital camera-to-data-logger connections.

Key Advantages

Increases Communication Options
Adds data link possibilities among data loggers, PCs, and sensors

Technical Description

The MD485 includes three ports (RS-232, CS I/O, RS-485) for connecting a PC, a data logger, or another MD485. Any two ports can be used at a time.

The MD485 can be configured to provide transparent communications, MD9 emulation, and PakBus networking. Although the MD485 can emulate an MD9, the MD485 can not be added to an existing MD9 network. PakBus networking requires the data loggers to use the PakBus communications protocol. PC400 or LoggerNet software is used to initiate and control the communications link.

Required Equipment

The MD485 is shipped with the 10873 cable and SC12 cable for connecting it to a PC or data logger. Point-to-point and point-to-multipoint networks use the following equipment:

PC running PC400 or LoggerNet software
At the computer site, an MD485 is connected to the computer via a pn 10873 cable.
At each data logger site, an MD485 is connected either to the data logger’s CS I/O port (not compatible with the CR200(X)-series) or the data logger’s RS-232 port (not compatible with the CR510 or CR10X). The SC12 serial cable connects an MD485 modem to the CS I/O port. The pn 18663 9-pin pin (male) to 9-pin pin (male) null modem cable connects the MD485 to the RS-232 port.
The CABLE2TP-L Two-Twisted-Pair 22-AWG Cable connects an MD485 to another MD485. Please note that when communicating at maximum distances and high data rates, a cable with polyethylene insulation is recommended.
CR200(X)-series, CR510, CR800, CR850, CR10X, CR1000, or CR3000 datalogger.
Power supply
Environmental enclosure. At each field site, the data logger, power supply, and MD485 should be housed in the enclosure if the equipment is not located in a building.

Powering the MD485

AC power is typically used at the computer site; a pn 15966 wall charger is required. At the field site, the MD485 is powered by the data logger through its CS I/O port. If the MD485 is connected to the data logger’s RS-232 port instead of the CS I/O port, or if the data logger was purchased before 12/97, a pn 14291 Field Power Cable is required. Phone-to-MD485 and spread spectrum radio-to-MD485 networks also require a power supply with a null modem port . An A100 adapter used with a PS150 or PS200 power supply provides this capability. The PS150 or PS200 is recharged via a wall charger or a solar panel.

Benefits

Compatible with most Campbell Scientific data loggers
Can be used with a phone modem, Ethernet link, or spread spectrum radio to extend the distance between the data logger and PC
Increases the distance allowed between a CC5MPX digital camera and a PakBus data logger
Extends the distance between AVW200 Vibrating-Wire Interfaces for situations where wireless communication is impractical
Internal buffering ensures that data is not lost during transmission and allows each side to operate at different baud rates
Includes gas tubes on the RS-485 ports and a ground lug for better surge protection
Communicates at rates up to 115.2 kbps

Specifications

Function: Permits a PC to address and communicate with one or more data loggers over a distance of up to 1,200 m.
Transmission Distance or Area: 1,219 m
(4,000 ft) Can increase distance by using more MD485s or combining with spread-spectrum radios, Ethernet, or phone.
Baud Rates: 1200, 9600, 19.2k, 38.4k, 57.6k, 115.2k bps
Voltage: 12 Vdc
(from data logger or pn 15966 wall charger)
Surge: Complies with IEC61000-4-5, test level 3
(±2 kV, 2 Ω coupling impedance)
Operating Temperature: -25° to +50°C
(standard)
-55° to 85°C
(extended)
Service Requirements: CABLE2TP two-twisted pair cables must be installed between networked data loggers and base.
Maximum Cable Length: 1,219 m
(4,000 ft)
Dimensions: 15.88 x 6.35 x 1.91 cm
(6.25 x 2.5 x 0.75 in.)
Weight: 127.6 g
(4.5 oz)

Current Drain

Standby Mode: 1.2 mA
Communicating: 2 to 7 mA

Power

Standby Mode: 14.4 mW
Communicating: 24 to 84 mW

ESD

Air Discharge: Complies with IEC61000-4-2, test level 4
(±15 kV)
Contact Discharge: Complies with IEC61000-4-2, test level 4
(±8 kV)

Accessories

(6)

Common Accessories

(5)

Other Accessories

(1)

18663
Null Modem Cable, 9-Pin PIn (Male) to 9-Pin Pin (Male)
This null modem cable can be used to connect the MD485 to the datalogger's RS-232 port.
Orderable

Replacement Parts

(4)

Ships With

(4)

Similar Products

(2)

Compatibility

Enclosure Considerations

A desiccated, non-condensing environment is required. The MD485 includes built-in keyhole flanges for mounting to the backplate of a Campbell Scientific enclosure.

Combining with Other Devices

The MD485 can be combined with our AVW200-series Vibrating Wire Interfaces, CC640 Digital Camera, Ethernet links, phone modems (including cellular), and spread spectrum radios. Field site equipment should be housed in an environmental enclosure. Information about configuring the other devices is provided in the user manuals.

Power Considerations

AC power is typically used at the computer site; a pn 15966 wall charger is required. At the field site, the MD485 is powered by the data logger through its CS I/O port. If the MD485 is connected to the data logger’s RS-232 port instead of the CS I/O port, or if the data logger was purchased before 12/97, a pn 14291 Field Power Cable is required. Phone-to-MD485 and spread spectrum radio-to-MD485 networks also require a power supply with a null modem port. An A100 adapter used with a PS150 or PS200 power supply provides this capability. The PS150 or PS200 is recharged via a wall charger or a solar panel.
