RETIRED ›
This product is no longer available and has been replaced by: CS106. Some accessories, replacement parts, or services may still be available.

Overview

The CS105 measured barometric pressure for the range of 600 to 1060 mb (approximately sea level to 12,000 feet). A 12 V switching circuit was included in the sensor; a datalogger control port was used to control 12 Vdc power to the sensor, reducing power consumption. A sensor warm-up time of up to 1 second was recommended.

Images


Specifications

  • Dimensions: 2.4" x 2.4" x 0.8" (6.1 x 6.1 x 2.0 cm)
  • Accuracy: ±0.5 mb @ +20°C
  • Temperature Range: -40° to 60°C

Compatibility

Datalogger Considerations

A 2.5-ft cable is supplied with the sensor for connection to the datalogger. The cable connects to a control port, single-ended analog input terminal, 12 V power terminal, and ground terminal on the datalogger.

Compatible Contemporary Dataloggers

CR200(X) Series CR800/CR850 CR1000 CR3000 CR5000 CR9000X

Compatible Retired Dataloggers

CR500 CR510 CR10 CR10X 21X CR23X CR9000 CR7X

Mounting

The CS105 is typically mounted next to the datalogger inside an ENC12/14 or larger enclosure. The very small ENC100 is available for housing the CS105 separately, in its own enclosure.
