CS15-L
Current Transducer
CS15-L
End of lifeConfigurableCurrent Transducer
Pricing
- Model:
- CS15-L
- Item Number:
- CS15-L
- Warranty:
- 1 year
Overview
The CS15 is a modified version of the CS10 Current Transducer developed specifically for our CR200(X)-series dataloggers. It monitors ac current along an electrical wire for the range of 0.15 A to 125 A.
Technical Description
The CS15 detects the ac current along an electrical wire using the magnetic field that is generated by that current. It is external to the wire jacket and has no direct electrical connection to the system. This transducer outputs a millivolt signal that our CR200(X)-series dataloggers can directly measure.
The CS15 can be used for motor or generator load condition monitoring, efficiency studies, intermittent fault detection, and rough submetering.
Benefits
- Ideal applications include motor or generator load conditions, efficiency studies, intermittent fault detection, and rough submetering
- No direct electrical connection to the electrical system
Specifications
- Measurement Range
- 0.15 to 125 A
- Frequency
- 50 and 60 Hz
- Insulation Resistance
- 100 MΩ
(@ 500 Vdc)
- High Potential
- 2000 V
- Rated Current
- 125 A
- Accuracy with 10 Ω Maximum Burden (resistive)
- Typically ±5% of actual value
(with provided multiplier)
- Operating Temperature Range
- -25° to +55°C
- Case Material
- Polypropylene resin
- Construction
- Epoxy encapsulated
- Outer Diameter
- 4.8 cm
(1.89 in.)
- Inner Diameter
- 1.9 cm
(0.75 in.)
- Height
- 1.7 cm
(0.67 in.)
