COM310
COM310
End of lifeVoice-Synthesized Modem
No longer available to order
This product is retained for service, documentation, and compatibility information.
Replaced by
- COM320
Voice Phone Modem
- Model:
- COM310
- Item Number:
- 43001
Overview
The COM310 enabled anyone to call a data logger via phone to receive a verbal report of real-time site conditions. The data logger could be programmed to report specific conditions or to allow a caller to select specific information by pressing numbers on a touch-tone phone. The COM310 supported data transfer rates of 9600 and 1200 baud between the data logger and PC.
We can no longer load or support custom word lists in this product.
Specifications
- Current Drain
- 100 µA
(quiescent)
140 mA(voice transmitting)
- Standard Operating Temperature Range
- -25° to +50°C
- Extended Operating Temperature Range
- -55° to +85°C
- Dimensions
- 16.0 x 4.3 x 9.1 cm
(6.3 x 1.7 x 3.6 in.)
- Weight
- 272 g
(10 oz)
Other Accessories
(2)4330
2-Wire Surge Protector
This surge protector helps suppress electrical transients traveling down the phone line before they impact the phone modem. Enclosure hardware is not included. The purchase of a surge protector is required only where phone line surge protection is NOT provided by the local telephone company.
Orderable6362
Surge Protector Kit for 2-Wire Modem with Mounting Hardware
This surge protector is identical to the 4330 surge protector except it includes hardware for attaching it to an enclosure. The purchase of a surge protector is required only where phone line surge protection is NOT provided by the local telephone company.
Orderable
Replacement Parts
(4)3768
2-Pin Screw Terminal Plug Connector
Green power connector is available to replace a connector that has been lost or damaged.
Orderable2365
Phone Cable
This phone cable is shipped with our land-line phone modems and is 182 in. long. The 2365 includes RJ11C connectors that can be run directly from the junction box to the socket on the modem.
Orderable6044
Grommet for #6 or #8 Screw
These grommets are commonly used with the 505 screws to secure our equipment to the backplates of our enclosures.
Orderable505
Screw #6-32 x .375 Pan Phillips
These screws, along with the 6044 grommets, are commonly used together to secure our equipment to the backplates of our enclosures.
Orderable
