HMP155A-L

HMP155A-L Vaisala Temperature/RH Probe

HMP155A-L Options - show details
-L ft cable per sensor

Allowed values: 0-1000 ft, increments of 1 ft

Campbell Scientific recommends:
  • 9 ft length—probe mounted to mast/leg at a 2 m height
  • 11 ft length—probe mounted to a CM202 at 2 m height
  • 14 ft length—probe mounted atop a CM106B, CM110, CM10, or UT10 via a CM202
  • 19 ft length—probe mounted atop a CM115 via a CM202
  • 24 ft length—probe mounted atop a UT20 via a CM202
  • 37 ft length—probe mounted atop a UT30 via a CM202
Add two feet to the cable length if you are mounting the enclosure on the leg base of a CM106B, CM110, CM115, or CM120 tripod.
Cable Termination Options - show details
-PT -PT w/Tinned Wires
With the -PT option, the cable terminates in pigtails that connect directly to the datalogger.
-PW -PW w/Pre-Wire Connector
With the -PW option, the cable terminates in a connector that attaches to a prewired enclosure.

Add to your Quote List


Product Details
Typically Ships Within 14 - 21 Days
Restockable Yes
Warranty 1 year
Compliance CE Compliance Image

The "Typically Ships Within" value is an estimate of the number of calendar days within which this product is ready to ship from Campbell Scientific. Orders with more than 10 built-to-order products will likely increase the time needed to prepare the order for shipping.

To estimate how long it will take to receive an order that contains multiple products, combine the longest Ships Within value with the transit time of the shipping method you select.

Some specialized products have long Ships Within values. Because of this, you might consider submitting a separate order for these products so your other products won't be delayed.

Ships With
(1) HMP155ACBL1-L Replacement Cable for HMP155A-L
(1) NIST Traceable Calibration Certificate
(1) Connector Cover from original manufacturer
(1) Instruction Sheet from original manufacturer

Common Accessories

SW12V

The SW12V provides a mechanism for older dataloggers that don't have a switched 12V port to control power to the HMP155A. The SW12V is recommended for applications where the sensor will be measured by a CR500, CR510, 21X, CR7, or a CR10 with a silver wiring panel.
RAD14

The RAD14 uses a double-louvered design that offers improved sensor protection from driving rain, snow, and insect intrusion. It also has lower self-heating in bright sunlight combined with higher temperatures (> 24°C (~75°F)) and low wind speeds (< 2m/s (~4.5 mph)), providing a better measurement.
41005-5

The 41005-5 14-Plate Gill Radiation Shield houses and protects the HMP155A Temperature and RH probe. Its louvered construction allows air to pass freely through the shield thereby keeping the probe at or near ambient temperature. The 41005-5 is white allowing it to reflect solar radiation.

Replacement Parts

HMP155ACBL1-L

HMP155ACBL1-L HMP155A-L Replacement Cable

The HMP155ACBL1 is a replacement cable for the HMP155A Temperature and RH Probe. It connects the sensor to the datalogger.
HMP155ACBL1-L Options - show details
-L ft per sensor cable

Allowed values: 1-1000 ft, increments of 1 ft

Campbell Scientific recommends:
  • 9 ft length—probe mounted to mast/leg at a 2 m height
  • 11 ft length—probe mounted to a CM202 at 2 m height
  • 14 ft length—probe mounted atop a CM106B, CM110, or UT10 via a CM202
  • 19 ft length—probe mounted atop a CM115 via a CM202
  • 24 ft length—probe mounted atop a UT20 via a CM202
  • 37 ft length—probe mounted atop a UT30 via a CM202
Add two feet to the cable length if you are mounting the enclosure on the leg base of a CM106B, CM110, CM115, or CM120 tripod.
Cable Termination Options - show details
-PT -PT w/Tinned Wires
With the -PT option, the cable terminates in pigtails that connect directly to the datalogger.
-PW -PW w/Pre-Wire Connector
With the -PW option, the cable terminates in a connector that attaches to a prewired enclosure.

HMP155ACBL2-L HMP155A-L Replacement RS-485 Cable

The HMP155ACBL2 is a replacement RS-485 cable for the HMP155A Temperature and RH Probe when being used for digital measurements.
HMP155ACBL2-L Options - show details
-L ft per sensor cable

Allowed values: 1-1000 ft, increments of 1 ft

Campbell Scientific recommends:
  • 9 ft length€”probe mounted to mast/leg at a 2 m height
  • 11 ft length€”probe mounted to a CM202 at 2 m height
  • 11 ft length€”probe mounted atop a CM6 via a CM202
  • 14 ft length€”probe mounted atop a CM106, CM110, CM10, or UT10 via a CM202
  • 19 ft length—probe mounted atop a CM115 via a CM202
  • 24 ft length—probe mounted atop a UT20 via a CM202
  • 37 ft length—probe mounted atop a UT30 via a CM202
Add two feet to the cable length if you are mounting the enclosure on the leg base of a CM106, CM110, CM115, or CM120 tripod.
Cable Termination Options - show details
-PT -PT w/Tinned Wires
With the -PT option, the cable terminates in pigtails that connect directly to the datalogger.
-PW -PW w/Pre-Wire Connector
With the -PW option, the cable terminates in a connector that attaches to a prewired enclosure.
32578

The 32578 is the the standard sintered PTFE (polytetrafluoroethylene) filter and O-ring for the HMP155A-L Temperature and Relative Humidity Probe.

Services


Order the 27727 to have Campbell Scientific recalibrate a temperature and RH probe. The accuracy of the recalibration is ± 2% from 10 to 90% RH and ± 3% from 90 to 100% RH. Campbell Scientific supplies before and after calibration sheets.
