Weather / Automatic Weather Stations (AWS) and Meteorologic Instruments

How We Can Help You

From single research weather stations to mesoscale weather networks (mesonets), Campbell Scientific automatic weather stations have become the worldwide standard for climate and boundary-layer meteorology. They are integral parts of forecasting and monitoring systems worldwide. Accurate measurements, low power requirements, and proven reliability in extreme weather conditions make our weather stations ideal for all types of meteorological and climatological monitoring anywhere on earth.

Learn more

To see how our systems meet your application needs, review our case studies »

For an introduction to our solutions that are compliant with World Meteorological Organization (WMO) and Global Basic Observing Networks (GBON) standards for the Systematic Observations Financing Facility (SOFF) initiative, visit our GBON-Compliant Observation Solutions page

Mesonet Essentials logo

For an introduction to mesonets, their value, and how they work, visit the Mesonet Essentials section.

Products






Customize a System

In addition to our standard systems available, many of the systems we provide are customized. Tell us what you need, and we’ll help you configure a system that meets your exact needs.

More Details about Our Automatic Weather Stations (AWS) and Meteorologic Instruments Systems

Data loggers for weather monitoring

Our weather stations are based around a programmable data logger (typically a CR1000 or CR3000) that measures the sensors, then processes, stores, and transmits the data. Our data loggers have wide operating temperature ranges, on-board instructions, programmable execution intervals, and ample input channels for commonly used sensors. Wind vector, wet bulb, histogram, and sample on maxima or minima are standard in the data logger instruction sets. Most sensors can be measured directly—without external signal conditioning.

Data are typically viewed and stored in the units of your choice (e.g., wind speed in mph, m/s, knots). Measurement rates and data recording intervals are independently programmable, allowing calculation of 15-minute, hourly, and daily data values from 1-minute or 1-second measurements, for example. Conditional outputs, such as rainfall intensity and wind gusts, can also be recorded. The program can be modified at any time to accommodate different sensor configurations or new data processing requirements. If needed, channel capacity can be expanded using multiplexers, including a model designed specifically for thermocouples.

Weather Sensors

Almost any meteorological sensor can be measured by our data loggers, allowing stations to be customized for each site. Typical sensors used on our stations include, but are not limited to:

  1. Wind speed and direction
  2. Solar radiation
  3. Temperature (air, water, soil)
  4. Relative humidity
  5. Precipitation
  6. Snow depth
  7. Barometric pressure
  8. Soil moisture

In some locations, hydrological sensors provide additional measurements, such as water level of a nearby stream.

Data Retrieval

We offer multiple communications options for data retrieval, which can be mixed within the same network. Telecommunications options include short-haul, telephone (landline, voice-synthesized, cellular), radio frequency, multidrop, and satellite. On-site options include storage module and laptop computer.

Software

Our PC-based support software simplifies the entire weather monitoring process, from programming to data retrieval to data display and analysis. Our software automatically manages data retrieval from networks or single stations. Robust error-checking ensures data integrity. We can even help you post your data to the Internet.

Example Weather Stations





Case Studies

Malawi: Enhancing Weather Observation through Public-Private Partnership
In 2019, Campbell Scientific embarked on a significant project with the Malawi Department of Climate......read more
Zambia: Strengthening Climate Resilience
Overview In May 2019, the Government of Zambia embarked on the Central Asia Water & Energy......read more
France: Preserving Prehistoric Treasures
Overview The Chauvet-Pont d'Arc and Aven d'Orgnac caves are home to prehistoric treasures of rare artistic......read more
France: Restoring a Royal Chapel
Overview The Royal Chapel of Chaalis Abbey—often referred to as the “French Sistine Chapel”—is a treasure......read more
Southern Africa: Empowering Conservation and Water Security
Introduction At Campbell Scientific, we are committed to providing cutting-edge weather station solutions to organizations around......read more
Croatia: Modernization of a Countrywide Weather Observation Network
Overview The National Weather Observation Network in Croatia, led by the Croatian Meteorological and Hydrological Service......read more
The Kingdom of eSwatini: Strengthening Early Warning Systems and Climate Services
Overview The Kingdom of eSwatini in Southern Africa—with its agricultural-based economy and a population of less......read more
South Africa: Fog Harvesting
Southwestern South Africa had three consecutive dry winters—from 2015 through 2017—resulting in the Cape Town......read more

Frequently Asked Questions

Number of FAQs related to Automatic Weather Stations (AWS) and Meteorologic Instruments: 1

  1. We manufacture a weather station for Hunter that they have integrated with some of their irrigation software and control packages. For details on rain shutoff capabilities and irrigation controls specific to Hunter systems, contact a Hunter distributor.
