Retired Product
Overview

Specifications

Compatibility

Ordering

Support

Image Gallery
Sections: Downloads, FAQs

General Support

User Forum

Visit the Campbell Scientific Forum to submit your question to users around the world.

Ask an Expert

Ask a Question using our simple form and we'll pass it along to one of our experts.

Call Us

Our Application Engineers are ready to answer your questions. Our support numbers are:

Technical Support
US Sales
International Sales
Order Entry
Accounts Receivable
Repairs 		435.227.9100
435.227.9120
435.227.9140
435.227.9090
435.227.9092
435.227.9105

Downloads

CR510 OS v.1.15 (640K) Add to List

Execution of this download installs the CR510 Operating System (Mixed-Array) on your computer.

Note: The Device Configuration Utility is used to upload the included operating system to the datalogger. Requires an SC32A or SC32B.

CR510-TD OS v.1.16 (645K) Add to List

Execution of this download installs the CR510 Table Data Operating System on your computer.

Note: The Device Configuration Utility is used to upload the included operating system to the datalogger. Requires an SC32A or SC32B.

Device Configuration Utility v.2.01 (31 MB) Download Now

A software utility used to download operating systems and set up Campbell Scientific hardware. Device Configuration Utility supports the following Campbell Scientific products: AVW200, CC5MPX, CC640, CD295, COM220, COM320, CR10X, CR10X-PB, CR10X-TD, CR23X, CR23X-PB, CR23X-TD, CR2xx, CR510, CR510-PB, CR510-TD, CR800, CR1000, CR3000, CR5000, CR9000X, CS120, CS450, CS650, CWB100, CWS220, CWS655, CWS900, EC100, MD485, NL1xx, NL200, OBS500, PS200/CH200, RF4xx, RF500M, SC105, SC115, SDM-CAN, SDM-SI01, SMxM, TGA100A and TX320.


View Revision History
CR510-PB OS v.1.10 (647K) Add to List

Execution of this download installs the CR510 PakBus Operating System on your computer.

Note: The Device Configuration Utility is used to upload the included operating system to the datalogger. Requires an SC32A or SC32B.

FAQ

Q. Why do I need an SC32B to connect my PC to my CR510, CR500, CR10(X), 21X, or CR7 datalogger?
The SC32B provides isolation between the datalogger and PC. It also converts the CMOS logic levels of our dataloggers to the RS-232 logic levels required by most computers.
..more
Q. Which protocol do you use to communicate your CR500 datalogger with the modem?

We communicate through the CS/IO port on the CR500 at 300, 1200 or 9600 bits per second, 8 data bits, no parity, 1 stop bit and no flow control.

Refer to Appendix B of the CR510 Manual for more information.

..more
Q. Can I use the manual for the CR510 to answer any questions I have regarding my CR5000?

The CR510 has all the channels, features and instructions that the CR500 has in addition to the following: The scan interval resolution is1/64 in the CR510 and 1/8 in the CR500. There is a Final Storage Area 2, in the CR510 that is not in the CR500. Battery backed clock in the CR510, that is not in the CR500. Memory: 128K Flash and 128K SRAM in CR510, CR500 only has 32k SRAM and 128k Flash. There are several programs in the CR510 that are not in the CR500. You can get 1 MB and 2 MB memory options for the CR510 that are not available in the CR500. Available Operating Systems in the CR510, were Standard, Modbus, Alert, Table Data and Pakbus. Only Standard Operating Software and Alert were available for the CR500.

..more
Q. Are CR510s and CR500s compatible with thermocouples?
No. If you intend to measure thermocouples, you should purchase a CR10X, CR23X, CR5000, CR7, or CR9000(C).
..more
Q. Are CR510s and CR500s compatible with SDMs and multiplexers?
These dataloggers are NOT compatible with SDMs or multiplexers. If you need more channels or might need more channels in the future, you should probably purchase a CR10X instead.
..more

Resources and Links

Ships With

(1) 1113 Flat screwdriver

(*) 17153 Operator's Manual w/Prompt sheet

(4) 505 Screw

(4) 6044 Grommet

*Ships With

Shipping Weights & Dims

Single Box Shipping Weight:
     9.0 lb
     4.1 kg

Single Box Shipping Dimensions:
     12" x 12" x 8"
     30.5 x 30.5 x 20.3 cm
