Avalanche, Ski, Alpine & Polar

Campbell Scientific provides rugged, low-power measurement systems for many applications in snowy climates. Our systems measure snow depth, snow-water equivalent, air temperature, relative humidity, and wind speed and direction. This data is useful for displaying current weather conditions, identifying snow-making conditions, forecasting spring runoff and summer water availability, and modeling avalanche conditions.

Read more

Dataloggers for unattended monitoring

Our monitoring stations are based around a programmable datalogger (typically a CR1000 or CR3000) that measures the sensors, then stores and transmits the data. We designed our dataloggers to provide a high level of station customization. They have programmable execution intervals, operating temperature ranges down to -55°C, on-board instructions for commonly used sensors, and adequate input channels to accommodate many different sensor configurations.

CR1000

If needed, channel capacity can be expanded using multiplexers, including a model designed specifically for thermocouples. Our dataloggers interface directly to most sensors, eliminating external signal conditioning. Powerful on-board instruction sets allow unattended control decisions based on time or conditional events. For example, peripherals such as heaters or specialized sensors can be actuated based on temperature, wind speed, solar radiation, or some other measured parameter or event. These instruction sets contain programmed algorithms that process measurements and output results in the desired units of measure. Wind vector, wet bulb, histogram, and sample on maxima or minima are all standard to the datalogger instruction sets.

CR3000

Measurement processing and data storage are programmable, but measurements are typically processed and stored at hourly and daily intervals (e.g., maxima, minima, averages). True averages can be calculated and stored by the dataloggers. Conditional outputs can also be processed and stored. For example, data can be stored at faster intervals based on events such as increased wind speeds or subnormal temperatures.

Sensors

Almost any sensor can be measured by our dataloggers, allowing stations to be customized for each site. Typical sensors used with our stations include, but are not limited to: relative humidity, solar radiation, wind speed and direction, air temperature, water temperature, soil temperature, precipitation, snow depth, barometric pressure, soil moisture, as well as strain gages, accelerometers, pressure transducers, GPS receivers, linear potentiometers, and many more.

Data Retrieval

We offer multiple communications options for data retrieval, allowing stations to meet exact needs. Telecommunication options include radio frequency, satellite (Argos, GOES), telephone (landline, voice-synthesized, cellular), short-haul, and multidrop. On-site options include storage module, laptop computer, and datalogger keyboard/display. Robust error-checking and low-power use ensure your data arrives uncorrupted and as scheduled. We can even help you post your data to the Internet.

Software

Our Windows-based software simplifies datalogger programming, data retrieval, and report generation. The datalogger program can be modified at any time to accommodate different sensor configurations or new data processing requirements.
