Campbell Scientific provides professional- and research-grade measurement systems for many applications within agriculture and plant-related markets. Our systems measure environmental parameters related to evapotranspiration, plant growth and development, and disease modeling. This data is useful for scheduling planting, irrigation, and harvesting; supporting automated weather alerts; and timing for pesticide applications.

Read more

ET107 Evapotranspiration Monitoring Station

Our ET107 ETo station consists of meteorological sensors, an aluminum 3-m pole, and an environmental enclosure that houses a CR1000M module and a 7-Ahr sealed...

GRWS100 General Research-Grade Weather Station

Mid-level, low-power, portable weather station that provides general meteorological measurements with the flexibility to be adapted to a wide arena of weather-based applications.

This is a...


Request Custom System

Customize a System

Most of the systems we sell are customized. Tell us what you need and we'll help you configure a system that meets your exact needs.

More Details about Our Agriculture & Plants Systems

Weather Stations and Evapotranspiration Stations

Our weather stations provide long-term, stand-alone monitoring of meteorological parameters for all types of agricultural research applications. Programmable dataloggers allow multiple options for station configuration, measurement and output intervals, and data retrieval. Almost any meteorological sensor can be used including: wind speed, wind direction, solar radiation, air temperature, water temperature, soil temperature, relative humidity, dew point, precipitation, leaf wetness, and barometric pressure. Wind vector, vapor pressure, histogram, and sample on maxima or minima are standard in the datalogger instruction sets. Data are typically viewed and stored in the units of your choice (e.g., wind speed in mph, m/s, knots).

Pre-programmed stations calculate potential evapotranspiration using the Penman-Monteith equation; other evapotranspiration algorithms can be entered if preferred.

Our evapotranspiration stations help provide an accurate method of estimating crop water needs to eliminate under- and over-watering, which saves money and improves crop quality. These automated stations calculate ETo using the Penman-Monteith equation. The output provides daily estimates of water needs. Our low-cost, preconfigured station calculates ETo from a reduced set of sensors.

System Components

Our stations are based around state-of-the-art instrumentation that features proven reliability, even in harsh environments. Most telecommunications and onsite communications methods are compatible with our systems, including phone (land-line, cellular, and voice-synthesized), radio, short haul and the Internet.

Surface Flux Measurements

Our flux systems can measure atmospheric gradients or vertical turbulent transport directly. Standard systems that support either aerodynamic or Bowen ratio gradient techniques are available for measuring heat, water vapor, and CO2 fluxes. Our standard eddy covariance systems use our three-dimensional sonic anemometer and either our open-path krypton hygrometer or our open-path H2O and CO2 analyzer.

Soil Measurements

We can measure nearly every commercially available soil sensor, including tensiometers, heat flux plates, thermocouples, psychrometers, lysimeters, and gypsum blocks.

Our soil water instrumentation is used extensively to monitor soil water content and soil water matric potential. Our time-domain reflectometry (TDR) systems provide accurate, reliable measurements of soil volumetric water content and bulk electrical conductivity in soils over a wide range of textures and soluble salt concentrations. We offer both long-term, multi-point (up to 512 probes) systems and a portable system for instantaneous soil water content readings. Our sensors that measure soil water matric potential use heat dissipation and electrical resistance methods.

Soil moisture sensors also provide water management information. They can be added to weather/evapotranspiration stations or used independently. For portable water content measurements, the hand-held HS2 HydroSense® II probe can be easily carried from site to site and provides instantaneous soil water content readings.

Agricultural Research System Components

Dataloggers

All of our measurement systems are based around programmable dataloggers that measure the sensors, then process or store the data. We designed our dataloggers to allow a high degree of flexibility. Measurement types, scan rates, and recording intervals are all programmable. On-board processing instruction sets contain programmed algorithms that process measurements and output results in the desired units of measure. Our dataloggers can also control external devices, such as valves and samplers.

Sensors

Most sensors, even those made by other manufacturers, interface directly to our dataloggers. Sensors used in our agricultural research (micromet) systems include sonic anemometers, hygrometers, fine wire thermocouples, and open path gas analyzers, and closed path gas analyzers.

Data Retrieval

We offer multiple communications options for data retrieval; options can be mixed within the same network. Telecommunications options include landline telephone, voice-synthesized telephone, cellular telephone, radio, multidrop, short-haul, and satellite. On-site options include storage module, PDA, and laptop computer.

Greenhouse and Growth Chamber Measurements

Our systems can be configured to provide accurate, stand-alone monitoring of greenhouse or growth chamber conditions for use in agricultural and plant physiology research applications. Programmable dataloggers allow multiple options for system configuration, measurement and output intervals, and data retrieval. A variety of sensors can be used including: solar radiation, temperature (air, water, soil), relative humidity, dew point, leaf wetness, and barometric pressure. Data are typically viewed and stored in the units of your choice. In addition, the system can easily be configured to monitor electrical power or water usage to provide data on consumption. The system can also be programmed to sound audible alerts or call out via voice synthesized modem if alarm-level conditions are reached.

Plant Physiology System Components

Dataloggers used in Plant Physiology

All of our measurement systems are based around programmable dataloggers that measure the sensors, then process or store the data. We designed our dataloggers to allow a high degree of flexibility. Measurement types, scan rates, and recording intervals are all programmable. On-board processing instruction sets contain programmed algorithms that process measurements and output results in the desired units of measure. Our dataloggers can also control external devices, such as valves and samplers.

Sensors used in Plant Physiology

Most sensors, even those made by other manufacturers, interface directly to our dataloggers. Sensors used in our agricultural research (micromet) systems include sonic anemometers, hygrometers, fine wire thermocouples, and open and closed path gas analyzers.

Data Retrieval

We offer multiple communications options for data retrieval; options can be mixed within the same network. Telecommunications options include telephone (landline, voice-synthesized, cellular), radio, multidrop, short-haul, and satellite. On-site options include storage module, PDA, displays, and laptop computer.

Resources and Links

Related FAQs

How much does a typical system cost?

Most Campbell Scientific systems are built from individual components. This provides maximum flexibility for our customers, but it does not lend itself to pricing a "typical" system. Contact an application engineer at Campbell Scientific for assistance in pricing a system to meet the unique needs of the application.
